TECHNICAL DATA SHEET

ATE-R23-38W

<FOR TOPLITE COB MODULE>

3 / 10

A/1

ATE-R23-38W SERIES

Revision issued in 2014.

3-2. ELECTRICAL-OPTICAL CHARACTERISTICS

**

PARAMETER

SYMBOL

CONDITION

MIN.

TYP.

MAX.

UNIT

common

34

36

39.6

V

Beam Angle

Deg

—

120

—

Deg

W

**

Color Temp.

2870

3045

3220

K

**

Ra

80

—

—

—

Φ

3420

3610

—

lm

Luminous Efficiency

η

90

95

—

lm/W

Φ

3800

3990

—

lm

Luminous Efficiency

η

100

105

—

lm/W

D

**

Color Temp.

4745

5028

5311

K

**

Ra

80

—

—

—

Φ

3800

3990

—

lm

Luminous Efficiency

η

100

105

—

lm/W

Φ

4180

4370

—

lm

Luminous Efficiency

η

110

115

—

lm/W

C

**

Color Temp.

6020

6530

7040

K

**

Ra

80

—

—

—

Φ

4370

4560

—

lm

Luminous Efficiency

η

115

120

—

lm/W

Φ

4590

4750

—

lm

Luminous Efficiency

η

121

125

—

lm/W

(Note) Parameters is formulated based on shipping samples

*1. After 20 ms drive, Measurement tolerance: ± 3 %

*2. Monitored by TOPLITE's 1 m integrating sphere, after 20 ms drive, Measurement tolerance: ± 10 %

*3. Monitored by TOPLITE's 1 m integrating sphere, after 20 ms drive, Measurement tolerance:± 2
