Data Sheet

AS01606MS-SC16-WP-R

PUI Audio’s Mobile Series line of speakers and receivers is designed for cutting-

edge applications such as smart watches and pendants, Wi-Fi enabled security

devices and action cameras, mobile radios and smart phones, as well as IoT

devices. Each Mobile Series product features an IP67-rated face for protection

against dust and water ingress.

The six ohm 16mm x 9mm AS01606MS-SC16-WP-R speaker is designed for

high fidelity audio reproduction in the thinnest size possible—only 3mm thick!

Spring contacts allow for easy electrical connection.

Features:

•

PEEK diaphragm for flat frequency response

•

91 dB output (2.37V @ 10cm)

•

High-energy neodymium motor

•

Only 3 mm thick

•

Dustproof and waterproof IP67-rated face

Specifications

Parameters

Values

Units

Rated Input Power

0.94

Watts

Max Input Power

1.2

Watts

Impedance

6 ± 20%

Ohms

Sensitivity (SPL @ 2.37V/10cm)

At 2 kHz

91 ± 3

dB

Resonant Frequency

(in 1cc enclosure)

850 ± 20%

Hz

Frequency Range

500 ~ 20,000

Hz

Frame Material

PPA

-

Magnet Material

NdFeB

-

Weight

1.2

Grams

Environmental Protection Rating

IP67

-
