Data Sheet

AS01808PR-N50-R

Introducing the N50 Mini Speaker Series from PUI Audio. High-grade

neodymium magnetic motors are employed in each N50 Series speaker to create

the highest output possible, in the smallest form factor.

The 18mm diameter AS01808PR-N50-R features a paper cone and inverted

foam surround for warm, classic tone and high power handling. Add high fidelity

sound to your product without sacrificing space!

Features:

•

Paper cone with inverted foam surround

•

High 78 dB output at 1W/50cm

•

N50 neodymium motor

•

Only 5.2mm thick

•

1.2mm of excursion

Specifications

Parameters

Values

Units

Rated Input Power

2

Watts

Max Input Power

2.8

Watts

Impedance

8 ± 15%

Ohms

Sensitivity (SPL @ 1W/50cm)

(800, 1000, 1200, and 1500 Hz)

78 ± 3

dBA

Distortion (Max @ 2W, 1 kHz)

<5%

Resonant Frequency

500 ± 20%

Hz

Frequency Range

300 ~ 20,000

Hz

Housing Material

ABS

Magnet Material

NdFeB

Weight

4.8

Grams
