Data Sheet

AS06606SR-R

More than ever before, high quality audio is the determining factor that

distinguishes your product from the fray. When the sound quality of your

product is on the line, choose High Fidelity speakers from PUI Audio.

The AS06606SR-R is a small, high-output, silk dome tweeter designed for

frequencies above 2 kHz, allowing it to be used for siren applications and can

also be used in combination with other speakers for high fidelity applications.

Features:

•

Silk dome diaphragm

•

30W max power handling (with 18 dB/octave 2 kHz high-pass filter)

•

High-energy shielded motor design with large heatsink

•

Capable of over 100 dB of output at 1 meter

•

Three screw-hole mounting flange with waveguide

•

Amplifier-friendly 6 ohm impedance

Specifications

Parameters

Values

Units

Rated Input Power

15

Watts

Max Input Power

30

Watts

Impedance

6 ± 15%

Ohms

Sensitivity (SPL @ 1W/1m)

Average 3, 5, 10, 15 kHz

90 ± 3

dB

Resonant Frequency

1,800± 20%

Hz

Frequency Range

1,500 ~ 20,000

Hz

Frame Material

ABS

-

Magnet Material

NdFeB

-

Weight

63

Grams
