isc website：www.iscsemi.com

isc & iscsemi is registered trademark

1

isc Triacs

ISC3A70W

FEATURES

·

With ITO-247 insulated package.

·

is suitable for general purpose AC switching and voltage regulation,

and can be used in static relays, heating regulation, induction motor

stating circuits.

·

Minimum Lot-to-Lot variations for robust device performance and

reliable operation.

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL

PARAMETER

MIN

UNIT

VDRM

Repetitive peak off-state voltage

1200

V

VRRM

Repetitive peak reverse voltage

1200

V

IT(RMS)

RMS on-state current @ TC=70℃

80

A

ITSM

Non-repetitive peak on-state current @ tp=20ms

800

A

Tj

Operating junction temperature

-45~125

℃

Tstg

Storage temperature

-45~150

℃

PG(AV)

Average gate power dissipation(Tj=125℃)

2

W

Rth(j-c)

Thermal resistance, junction to case

0.35

℃

/W

ELECTRICAL CHARACTERISTICS (TC=25℃ unless otherwise specified)

SYMBOL

PARAMETER

CONDITIONS

MAX

UNIT

IRRM

Repetitive peak reverse current

VR=VRRM,

VR=VRRM, Tj=125℃

0.02

10

mA

IDRM

Repetitive peak off-state current

VD=VDRM,

VD=VDRM, Tj=125℃

0.02

10

mA

IGT

Gate trigger current

Ⅰ

VD=12V; RL= 33Ω

50

mA

Ⅱ

50

Ⅲ

50

IH

Holding current

IGT= 0.1A

80

mA

VGT

Gate trigger voltage all quadrant VD=12V; RL= 33Ω

1.3

V

VTM

On-state voltage

IT= 120A; tp= 380μs

1.6

V
