26/11/2019

Connectors System AC 166®

Cord Set

AC 166 ALCGB/525 050 pastel blue black

Extension Cable Socket, 5 pole, pastel blue black, Coding: 5 (DALI),

Cable Type: H05VV-F, Core Cross-Section: 2.5 mm², Fire Class: Eca,

Length: 0.50 m, Voltage Rating: 250/400 V, Current Rating: 20 A

Order Info

Reference Number (ref. no.)

1663P505

PU

30

Type

Type

Extension Cable Socket

Number of poles

5 pole

Colour

pastel blue black

Coding

5 (DALI)

PE Function

yes

Technical Data

Voltage Rating

250/400 V

Current Rating

20 A

Insulating Material

PA 6.6

Contact Material

Brass

max. Ambient Temperature Operation

70 °C

IP Code

IP20

IP Code when Plugged

IP40

Type of Conductor Flexible

yes

Stripping Length

9.0 mm

Dismantling Length PE

52.0 mm

Dismantling Length

45.0 mm

Cable Type

H05VV-F

Core Cross-Section

2.5 mm²

Fire Class

Eca

Length

0.50 m

Approbation EN61535

AC166-G_Leitungen_EN61535_20121212_20180725_VDE_ENEC_40036146_web.pdf
