FUZETEC TECHNOLOGY CO., LTD.

NO.

PQ40-01E

Product Specification and Approval Sheet Version

2

Page

1/4

NOTE : Specification subject to change without notice.

2017/08/07

Surface Mountable PTC Resettable Fuse : FSMD2016 Series

1. Summary

(a) RoHS Compliant & Halogen Free

(b) Applications : All high-density boards

(c) Product Features : Small surface mount, Solid state, Faster time to trip than

standard SMD devices, Lower resistance than standard SMD devices

(d) Operation Current : 0.3A~2.0A

(e) Maximum Voltage : 6~60VDC

(f) Temperature Range : -40℃ to 85℃

2. Agency Recognition

UL :

File No. E211981

C-UL:

File No. E211981

TÜ V:

*File No. R50090556

*FSMD030-2016-R~FSMD050-2016R, FSMD150-2016-R~FSMD200-2016-R TÜ V In Process.

3. Electrical Characteristics (23℃)

Part

Number

Hold

Current

Trip

Current

Rated

Voltage

Max

Current

Typical

Power

Max Time to Trip

Resistance

Current

Time

RMIN

R1MAX

IH, A

IT, A

VMAX,VDC

IMAX, A

Pd, W

A

Sec

Ohms

FSMD030-2016-R

0.30

0.60

60

100

1.4

1.5

3.0

0.400

2.300

FSMD050-2016R

0.55

1.10

60

100

1.4

2.5

5.0

0.200

1.000

FSMD100-2016-R

1.10

2.20

15

100

1.4

8.0

0.5

0.070

0.400

FSMD100-33-2016-R

1.10

2.20

33

100

1.4

8.0

0.5

0.070

0.400

FSMD150-2016-R

1.50

3.00

15

100

1.4

8.0

0.8

0.050

0.180

FSMD200-2016-R

2.00

4.20

6

100

1.4

8.0

3.0

0.030

0.100

IH=Hold current-maximum current at which the device will not trip at 23℃still air.

IT=Trip current-minimum current at which the device will always trip at 23℃ still air.

V MAX=Maximum voltage device can withstand without damage at it rated current.(I MAX)

I MAX= Maximum fault current device can withstand without damage at rated voltage (V MAX).

Pd=Typical power dissipated-type amount of power dissipated by the device when in the tripped state in 23℃ still air environment.

RMIN=Minimum device resistance at 23℃ prior to tripping.

R1MAX=Maximum device resistance at 23℃ measured 1 hour after tripping or reflow soldering of 260℃ for 20 seconds.

Termination pad characteristics

Termination pad materials : Pure Tin
