FUZETEC TECHNOLOGY CO., LTD.

NO.

PQ04-01ER

Product Specification and Approval Sheet Version B1

Page

1/5

NOTE : Specification subject to change without notice.

2017/9/13

Surface Mountable PTC Resettable Fuse: FSMD1812 Series

1. Summary

(a) RoHS Compliant & Halogen Free

(b) Applications: All high-density boards

(c) Product Features: Small surface mountable, Solid state, Faster time to trip than

standard SMD devices, Lower resistance than standard SMD devices

(d) Operation Current: 0.10A~3.00A

(e) Maximum Voltage: 6V~60VDC

(f) Temperature Range : -40℃ to 85℃

2. Agency Recognition

UL:

File No. E211981

C-UL:

File No. E211981

TÜ V:

File No. R50004084, R50090556

3. Electrical Characteristics (23℃)

Part

Number

Hold

Current

Trip

Current

Rated

Voltage

Max

Current

Typical

Power

Max Time to Trip

Resistance

Current

Time

RMIN

R1MAX

IH, A

IT, A

VMAX, VDC

IMAX, A

Pd, W

Amp

Sec

Ohms

FSMD010-R

0.10

0.30

60

100

0.8

8.0

0.020

1.600

15.000

FSMD014-R

0.14

0.30

60

100

0.8

8.0

0.008

1.200

6.500

FSMD020-R

0.20

0.40

30

100

0.8

8.0

0.020

0.800

5.000

FSMD020-60-R

0.20

0.40

60

100

0.8

8.0

0.020

0.800

5.000

FSMD030-R

0.30

0.60

30

100

0.8

8.0

0.100

0.200

1.750

FSMD035-R

0.35

0.70

16

100

0.8

8.0

0.100

0.320

1.500

FSMD035-30-R

0.35

0.70

30

100

0.8

8.0

0.100

0.320

1.500

FSMD050-R

0.50

1.00

16

100

0.8

8.0

0.150

1.000

FSMD050-30-R

0.50

1.00

30

100

0.8

8.0

0.150

1.000

FSMD075-R

0.75

1.50

16

100

0.8

8.0

0.200

0.110

0.450

FSMD075-24R

0.75

1.50

24

100

1.0

8.0

0.200

0.110

0.290

FSMD075-33R

0.75

1.50

33

100

1.0

8.0

0.200

0.110

0.400

FSMD110-R

1.10

2.20

8

100

0.8

8.0

0.300

0.040

0.210

FSMD110-16-R

1.10

2.20

16

100

0.8

8.0

0.500

0.060

0.180

FSMD110-24R

1.10

2.20

24

100

1.0

8.0

0.500

0.060

0.200

FSMD110-33R

1.10

2.20

33

100

0.8

8.0

0.500

0.060

0.200

FSMD125-R

1.25

2.50

6

100

0.8

8.0

0.400

0.050

0.140

FSMD125-16R

1.25

2.50

16

100

0.8

8.0

0.400

0.050

0.140

FSMD150-R

1.50

3.00

8

100

0.8

8.0

0.500

0.040

0.110

FSMD150-12R

1.50

3.00

12

100

1.0

8.0

0.500

0.040

0.110

FSMD150-24R

1.50

3.00

24

100

1.0

8.0

1.500

0.040

0.120

FSMD160-R

1.60

3.20

8

100

0.8

8.0

0.500

0.030

0.100

FSMD160-12R

1.60

3.20

12

100

1.0

8.0

1.000

0.030

0.100

FSMD160-16R

1.60

3.20

16

100

1.0

8.0

1.000

0.030

0.100

FSMD200R

2.00

3.50

8

100

1.0

8.0

2.000

0.020

0.070

FSMD200-16R

2.00

3.50

16

100

1.0

8.0

5.000

0.020

0.085

FSMD260R

2.60

5.00

8

100

1.0

8.0

2.500

0.015

0.047
