MPI25-V1

High current, low profile, miniature power inductors

Technical Data Preliminary

030817

Product features

•

High current carrying capacity in compact

standard 1008 (2520 metric) footprint

•

Magnetically shielded, Low EMI

•

Rugged flexible construction

•

Inductance range from 0.33 µH to 4.7 µH

•

Current range from 1.22 A to 6.8 A

•

2.7 mm x 2.2 mm footprint surface mount

package in 1.0 mm and 1.2 mm heights

•

Moisture Sensitivity Level (MSL): 1

Applications

•

Smart phones

•

Handheld/mobile devices

•

Digital cameras

•

Media players

•

GPS

•

MP3 Players

•

Wearable electronics

•

Tablets/e-readers

Environmental

Environmental data

data

•

Storage temperature range (Component):

-40

°C to +125 °C

•

Operating temperature range: -40

°C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

•

Halogen free, lead free, RoHS compliant
