Technical Data Preliminary

030817

MPI25-V1

High current, low profile, miniature power inductors

www.eaton.com/electronics

Product specifications

Product specifications

Product specifications

Product specifications

1.

Open Circuit Inductance (OCL) Test Parameters: 1.0 MHz, 0.1 V

+25 ºC

2.

I

loss. Derating is necessary for AC currents. PCB layout, trace thickness and

width, air-flow, and proximity of other heat generating components will affect

the temperature rise. It is recommended that the temperature of the part not

exceed +125 ºC under worst case operating conditions verified in the end

application.

3.

I

4.

K-factor: Used to determine Bp-p for core loss (see graph). Bp-p = K * L * I. Bp-

p:(Gauss), K: (K-factor from table), L: (Inductance in µH), I (Peak to peak ripple current in

Amps).

5.

Part Number Definition: MPI25xxV1-xxx-R

MPI25 = Product code

xx= Height indicator

V1=Versionl indicator

xxx= inductance value in µH, R= decimal point,

If no R is present then last character equals number of zeros

-R suffix = RoHS compliant

2

Dimensions

Dimensions

Dimensions

Dimensions---- mm

mm

mm

mm

( µ H ) ±2 0 %

2

( A )

3

( A )

D C R ( m Ω

Ω

Ω

Ω) t y p i c a l

@ + 2 0 °C

D C R ( m Ω

Ω

Ω

Ω ) m a x i m um

@ + 2 0 °C

S R F

( M H z )

t y p i c a l

M P I2510V1-R33-R

0.33

4.0

6.6

21

26

199

2837

M P I2510V1-R47-R

0.47

4.4

6.6

23

29

154

2699

M P I2510V1-R68-R

0.68

3.1

4.3

37

44

118

2599

M P I2510V1-1R0-R

1.0

3.1

4.4

41

52

94

2451

M P I2510V1-1R5-R

1.5

2.3

2.6

76

91

74

1705

M P I2510V1-2R2-R

2.2

2.1

3.3

88

110

58

1710

M P I2510V1-4R7-R

4.7

1.22

1.8

220

262

41

849

M P I2512V1-R47-R

0.47

4.9

6.8

16

22

156

2306

M P I2512V1-R68-R

0.68

3.4

5.0

29

35

128

2084

M P I2512V1-1R0-R

1.0

3.3

4.8

36

44

85

2040

M P I2512V1-1R5-R

1.5

2.3

3.2

64

77

71

1431

M P I2512V1-2R2-R

2.2

2.2

3.5

74

89

55

1193

M P I2512V1-4R2-R

4.2

1.4

1.9

196

235

40

975

1. 0 mm hei g ht

1. 2 mm hei g ht
