www.hygroup.com.tw

D6KB05 THRU D6KB10

Features

D3K

●

Glass passivated chip

●

Low forward voltage drop

RoHS

●

Ideal for printed circuit board

COMPLIANT

●

High surge current capability

●

Meet UL flammability classification 94V-0

Mechanical Data

●

Polarity: Symbol marked on body

●

Mounting position: Any

Note: Products with logo

or

are made by HY Electronic (Cayman) Limited.

Applications

●

General purpose use in AC/DC bridge full wave rectification,

for SMPS, lighting ballaster, adapter, etc.

Maximum Ratings and Electrical Characteristics

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Characteristics

Symbol D6KB05 D6KB1 D6KB2 D6KB4 D6KB6 D6KB8 D6KB10

Unit

Maximum Repetitive Peak Reverse Voltage

50

100

200

400

600

800

1000

V

Maximum RMS Voltage

35

70

140

280

420

560

700

V

Maximum DC Blocking Voltage

50

100

200

400

600

800

1000

V

A

Peak Forward Surge Current, 8.3mS Single Half Sine-Wave,

Superimposed on Rated Load (JEDEC Method)

I

I

A

Peak Forward Voltage per Diode at 3.0A DC

V

Typical Thermal Resistance to Ambient

Typical Thermal Resistance to case

Typical Thermal Resistance to lead

Operating Junction Temperature Range

℃

Storage Temperature Range

℃

Note: The typical data above is for reference only

D6KB*-U-00/92-00/01

Rev. 11, 18-May-2020

Glass Passivated Bridge Rectifiers

170

500

-55 to +150

-55 to +150

Reverse Voltage - 50 to 1000 Volts

Forward Current - 6.0 Amperes

Package Outline Dimensions in Inches (Millimeters)

6

Pb

A

℃/W

μA

1.0

45

6

9

5.0

119.9
