CSM_E5CS_DS_E_5_3

Temperature Controllers

E5CS

Simple Functions in DIN 48

× 48 mm-size

Plug-in Temperature Controllers

• Easy setting using DIP switch.

• Models with two alarms added to Series, ideal for applications

requiring alarms.

• Universal-input (thermocouple/platinum resistance

thermometer) models also available.

• Clearly visible digital display with character height of 13.5 mm.

• RoHS compliant.

Refer to Safety Precautions for All Temperature

Controllers.

Refer to E5CS/E5CSV Operation for

operating procedures.

For the most recent information on models that have been certified for

safety standards, refer to your OMRON website.

Model Number Structure

■ Model Number Legend

Plug-in Models

3

Note: A functional explanation is provided here for illustration, but models are not necessarily available for all possible combinations. Refer to

Ordering Information

when ordering.

Examples

• Relay control output, without alarm, thermocouple input, plug-in construction, light gray case: E5CS-RKJU-W

• Relay control output, one alarm output, platinum resistance thermometer input, plug-in construction, light gray case: E5CS-R1PU-W

1 2 3 45

6

E5CS-

@@@@U-W

1. Control Outputs

R: Relay

Q: Voltage for driving SSR

2. Alarm Outputs

Blank: No alarm

1:

1 alarm

2:

2 alarms

3. Input

KJ: Thermocouple

P:

Platinum resistance thermometer

G: Thermistor

T:

Thermocouple/platinum resistance

thermometer (universal-input)

4. Power Supply Voltage

Blank: 100 to 240 VAC

D:

24 VAC/VDC

5. Terminal Shape

U:

Plug-in

6. Case Color

W:

Light gray
