Features

SMB

●

Fast switching for high efficiency

●

Low reverse leakage current

RoHS

●

High current capability

COMPLIANT

●

Low forward voltage drop

●

Low cost

●

Meet UL flammability classification 94V-0

Mechanical Data

●

Case: JEDEC SMB molded plastic

●

Polarity: Color band denotes cathode

●

Mounting position: Any

Note: Products with logo

are made byHY Electronic (Cayman) Limited.

Applications

●

For use in SMPS, high frequency inverters, PWM and polarity

protection applications

Maximum Ratings and Electrical Characteristics

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Characteristics

Symbol

RS3AB

RS3BB

RS3DB

RS3GB

RS3JB

RS3KB

RS3MB

Unit

Maximum Repetitive Peak Reverse Voltage

50

100

200

400

600

800

1000

V

Maximum RMS Voltage

35

70

140

280

420

560

700

V

Maximum DC Blocking Voltage

50

100

200

400

600

800

1000

V

A

Peak Forward Surge Current, 8.3mS Single Half Sine-Wave,

Superimposed on Rated Load (JEDEC Method)

Peak Forward Voltage at 3.0A DC (Note1)

V

Maximum Reverse Recovery Time (Note 2)

250

nS

Typical Junction Capacitance (Note3)

pF

Typical Thermal Resistance Junction to Lead

℃/W

Operating Junction Temperature Range

℃

Storage Temperature Range

℃

4. The typical data above is for reference only.

RS3*B-13-00-00/01

Rev. 11, 18-May-2020

1.3

3.0

100

150

500

5.0

-55 to +150

-55 to +150

2. Measured with IF=0.5A,IR=1A,IRR=0.25A .

3. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.

Notes:

1. 300uS pulse width, 2%duty cycle.

15

40

65

100

μA

www.hygroup.com.tw

RS3AB THRU RS3MB

Reverse Voltage - 50 to 1000 Volts

Forward Current - 3.0 Amperes

A

Pb

Surface Mount Fast Recovery Recitifiers

Package Outline Dimensions in Inches (Millimeters)

or
