July 2005

ASM3P623S00A/B/C/D/E/F

rev 1.0

Zero Cycle Slip Peak EMI Reduction IC

4 of 16

Notice: The information in this document is subject to change without notice.

Differential Cycle Slips and Spread Spectrum Control Table

(Note: The values given in the table are for an input frequency of 32 MHz)

Device

SS%

Deviation

Differential Cycle Slips

(Nd)

0

±0.5 %

0.125

ASM3P623S00A

1

±1 %

0.25

0

±0.25 %

0.125

ASM3P623S00B

1

±0.5 %

0.25

0

±0.125 %

0.125

ASM3P623S00C

1

±0.25 %

0.25

0

±0.5 %

0.125

ASM3P623S00D

1

±1 %

0.25

0

±0.25 %

0.125

ASM3P623S00E

1

±0.5 %

0.25

0

±0.125 %

0.125

ASM3P623S00F

1

±0.25 %

0.25

Absolute Maximum Ratings

Parameter

Min

Max

Unit

Supply Voltage to Ground Potential

-0.5

+7.0

V

DC Input Voltage (Except CLKIN)

-0.5

VDD + 0.5

V

DC Input Voltage (CLKIN)

-0.5

7

V

Storage Temperature

-65

+150

°C

Max. Soldering Temperature (10 sec)

260

°C

Junction Temperature

150

°C

Static Discharge Voltage

(As per JEDEC STD22- A114-B)

2000

V

Note: These are stress ratings only and functional usage is not implied. Exposure to absolute maximum ratings for prolonged periods can affect device

reliability.
