July 2005

ASM3P623S00A/B/C/D/E/F

rev 1.0

Zero Cycle Slip Peak EMI Reduction IC

5 of 16

Notice: The information in this document is subject to change without notice.

Operating Conditions for ASM3P623S00A/B/C and ASM3P623S00D/E/F Devices

Parameter

Description

Min

Max

Unit

VDD

Supply Voltage

3.0

3.6

V

Operating Temperature (Ambient Temperature)

0

70

°C

Load Capacitance

30

pF

Input Capacitance

7

pF

Electrical Characteristics for ASM3P623S00A/B/C and ASM3P623S00D/E/F

Parameter

Description

Test Conditions

Min

Typ

Max

Unit

Input LOW Voltage

5

0.8

V

Input HIGH Voltage

5

2.0

V

Input LOW Current

50

µA

Input HIGH Current

100

µA

Output LOW Voltage

6

0.4

V

Output HIGH Voltage

6

2.4

V

Supply Current

Unloaded outputs

15

mA

Output Impedance

23

Ω

Switching Characteristics for ASM3P623S00A/B/C and ASM3P623S00D/E/F

7

Parameter

Description

Test Conditions

Min

Typ

Max

Unit

Output Frequency

30pF load

20

50

MHz

Duty Cycle

Measured at VDD/2

40

50

60

%

Output Rise Time

6

Measured between 0.8V and 2.0V

2.5

nS

Output Fall Time

6

Measured between 2.0V and 0.8V

2.5

nS

Output-to-output skew

6

All outputs equally loaded

250

pS

Delay, CLKIN Rising Edge to

CLKOUT Rising Edge

6

Measured at VDD /2

±350

pS

Device-to-Device Skew

6

Measured at VDD/2 on the CLKOUT pins

of the device

700

pS

Cycle-to-cycle jitter

6

Loaded outputs

200

pS

PLL Lock Time

6

Stable power supply, valid clock presented

on CLKIN pin

1.0

mS

Notes:

5. CLKIN input has a threshold voltage of VDD/2

6. Parameter is guaranteed by design and characterization. Not 100% tested in production

7. All parameters specified with loaded outputs.
