ASM3P623S00A/B/C/D/E/F

rev 1.0

Zero Cycle Slip Peak EMI Reduction IC

3 of 16

Notice: The information in this document is subject to change without notice.

Pin Description for ASM3P623S00A/B/C

Pin #

Pin Name

Description

1

CLKIN

2

Input reference frequency, 5V-tolerant input

2

NC

No Connect

3

SS%

4

Spread Spectrum Selection

4

GND

Ground

5

SSON

4

Spread Spectrum enable and disable option When SSON is HIGH, the spread

spectrum is enabled and when LOW, it turns off the spread spectrum.

6

CLKOUT

1,3

Buffered clock output

7

VDD

3.3V supply

8

NC

No Connect

Pin Description for ASM3P623S00D/E/F

Pin #

Pin Name

Description

1

CLKIN

2

Input reference frequency, 5V tolerant input

2

CLKOUT1

3

Buffered clock output

3

VDD

3.3V supply

4

SS%

4

Spread Spectrum Selection

5

GND

Ground

6

CLKOUT2

3

Buffered clock output

7

CLKOUT3

3

Buffered clock output

8

DLY CNTRL

The pin is used to skew the outputs such that they align with the input. The skew can

is in the range of 100-200pS

9

SSON

4

Spread Spectrum enable and disable option. When SSON is HIGH, the spread

spectrum is enabled and when LOW, it turns off the spread spectrum.

10

CLKOUT4

3

Buffered clock output

11

CLKOUT5

3

Buffered clock output

12

GND

Ground

13

VDD

3.3V supply

14

CLKOUT6

3

Buffered clock output

15

CLKOUT7

3

Buffered clock output

16

CLKOUT8

3

Buffered clock output

Notes:

1. This output is driven and has an internal feedback for the PLL.

2. Weak pull-down. 3. Weak pull-down on all outputs. 4. Weak pull-up on these inputs.
