Quectel L70-RL

Compact GPS Module

with Built-in LNA and

Ultra Low Power Consumption

Build a Smarter World

L70-RL, a low cost ROM-based GPS module, brings the high performance of MTK positioning engine to industrial applications

with its compact profile, ultra low power consumption and fast positioning capability. Designed to be compatible with

Quectel L70-R module in the compact and unified form factor, L70-RL additionally provides a built-in LNA for better sensitivity

in weak signal areas.

Combining advanced AGPS called EASY™ (Embedded Assist System) technology, L70-RL achieves the highest performance

and fully meets the industrial standard. EASY™ technology ensures L70-RL can calculate and predict orbits automatically using

the ephemeris data (up to 3 days) stored in internal RAM memory, so L70-RL can fix position quickly even at indoor signal

levels with low power consumption.

With its extremely compact design, high precision and improved sensitivity, L70-RL is a perfect solution for a broad range of

M2M applications such as portable device, automotive, personal tracking, security and industrial PDA.

Key

Benefits

Extremely compact size: 10.1mm × 9.7mm × 2.5mm

Cost-efficient ROM-based version

Ultra low power consumption in tracking mode: 18mA

Support EASY™, an advanced AGPS technology without the

demand of external memory

Built-in LNA for better sensitivity

High sensitivity: -167dBm @Tracking, -149dBm @Acquisition

66 acquisition channels, 22 tracking channels

Support QZSS

Balloon mode, for high altitude up to 80km

PPS VS. NMEA can be used for time service

Great anti-jamming performance due to multi-tone active

interference canceller

EASY™ Technology

Ultra Low Power

Consumption

GPS+QZSS

RoHS Compliant

EMAIL US: info@quectel.com

VISIT US: www.quectel.com

Extended Temperature

Range: -40°C ~ +85°C

Extremely Compact

Size

Super Tracking

Sensitivity:

-167dBm

Anti-jamming
