KEMET EMC Filters

1

FLLE2 – R

Single phase EMI Filter

Single phase EMC Filter

May 2020

Overview

General purpose, single phase filter series with high attenuation. Chassis

mount for fast mounting, metal case filled with self-extinguishing resin.

Fast-on or screw terminals available and options with flexible wire

connections. Medical versions available without y-capacitors for no

leakage current.

Technical specifications

Typical electrial schematics

Components

Item

Parameters/

Characteristics

Rated Voltage

300 VAC/ VDC

Rated Frequency

50 - 60 Hz

Rated Current

1 - 32 A

Rated Temperature

40°C

Temperature range

-25°Cto 100°C

Climate Category

25/ 100/ 21

P -> N 1300 VDC

P/ N -> E 2250 VDC

Voltage Test

Part Number

Rated Current

@ 40°C

Leakage

Current *)

R

L1

L2

(A)

(mA)

(µF)

(M

Ω)

(mH)

(nF)

(µF)

(mH)

FLLE2001AR(1)(2)

1

0.37

0.22

1

12

4.7

0.22

12

FLLE2003AR(1)(2)

3

0.37

0.22

1

2.5

4.7

0.22

2.5

FLLE2006AR(1)(2)

6

0.37

0.22

1

1

4.7

0.22

1

FLLE2010AR(1)(2)

10

0.37

0.47

0.47

1

4.7

0.47

1

FLLE2013AR(1)(2)

13

0.37

0.47

0.47

0.6

4.7

0.47

0.6

FLLE2016AR(1)(2)

16

0.37

0.47

0.47

0.6

4.7

0.47

0.6

FLLE2020AR(1)(2)

20

0.37

1

0.22

0.8

4.7

1

0.8

FLLE2025AR(1)(2)

25

0.37

1

0.22

0.8

4.7

1

0.8

FLLE2032AR(1)(2)

32

0.79

1

0.22

0.8

10

1

0.8

(1) D= Standard, M = Medical

(2) B = Fast-on (1-16A), I = Threaded (20-32A), D= Wire (1-32A)

*) Leakage current @250 VAC/ 50 Hz acc. to IEC60939-3. Medical version without C

RoHS

Compliant
