RS3AB thru RS3MB

Pb Free Plating Product

RS3AB thru RS3MB

3.0 AMPERE GLASS PASSIVATED SURFACE MOUNT FAST RECOVERY RECTIFIERS

Pb

© 1995 Thinki Semiconductor Co., Ltd.

http://www.thinkisemi.com.tw/

Page 1/2

Rev.10T

Case:SMB/DO-214AA Package

Terminals: Solder plated, solderable per MIL-STD-750,

Method 2026

Polarity: Color band denotes cathode band

Mounting Position: Any

Weight:

The plastic package carries Underwriters Laboratory

Flammability Classification 94V-0

For surface mounted applications

Low reverse leakage

Built-in strain relief,ideal for automated placement

High forward surge current capability

High temperature soldering guaranteed:

250 C/10 seconds at terminals

FEATURE

MECHANICAL DATA

Glass passivated chip junction

0.11 gram approximately

APPLICATION

LED SMPS/Industrial power supply

HID ballast stabilizer/Audio amplifier

Telecommunication SMPS/LED street lamp

OUTLINE

Unit:inch(millimeter)

SMB/DO-214AA

Cathode Band

0.155 (3.94)

0.130 (3.30)

0.012 (0.305)

0.006 (0.152)

0.008 (0.2)

0 (0)

0.220 (5.59)

0.205 (5.21)

0.060 (1.52)

0.030 (0.76)

0.096 (2.44)

0.084 (2.13)

0.180 (4.57)

0.160 (4.06)

0.086 (2.20)

0.077 (1.95)

Ratings at

ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

25

°C

Absolute Maximum Ratings and Characteristics

Maximum DC Blocking Voltage

Peak Forward Surge Current 8.3 ms Single Half

Sine Wave Superimposed on Rated Load

Maximum Forward Voltage at 3 A

Parameter

Maximum Repetitive Peak Reverse Voltage

Maximum RMS voltage

Operating and Storage Temperature Range

Maximum Average Forward Rectified Current

Typical Junction Capacitance

at V =4V, f=1MHz

R

T , T

j

stg

V

V

V

3

90

5

100

4

0

-55 ~ +150

A

A

V

μA

ns

°C

Symbols

Maximum Reverse Recovery Time

pF

Units

1.3

Typical Thermal Resistance

R

θJC

48

16

°C/W

（1）

（2）

Maximum DC Reverse Current

T = 25

°C

a

at Rated DC Blocking Voltage

T =125

°C

a

50

100

200

400

600

800

1000

35

70

140

280

420

560

700

50

100

200

400

600

800

1000

150

250

500

RS3MB

RS3AB

RS3BB

RS3DB

RS3GB

RS3JB

RS3KB

.

（2）

（1）Measured with I = 0.5 A, I = 1 A, I = 0.25 A

F

R

rr

P.C.B. mounted with 2.0" X 2.0" (5 X 5 cm) copper pad areas.
