EMC Components

MMZ2012 type

CHARACTERISTICS SPECIFICATION TABLE

Measurement equipment

＊ Equivalent measurement equipment may be used.

Impedance

DC resistance

Rated current

Part No.

[100MHz]

(

)

Tolerance

(

)max.

(mA)max.

15

±25%

0.05

1500

MMZ2012Y150BTD25

30

±25%

0.05

1500

MMZ2012Y300BTD25

60

±25%

0.10

1000

MMZ2012Y600BTD25

120

±25%

0.12

800

MMZ2012Y121BTD25

300

±25%

0.15

600

MMZ2012Y301BTD25

600

±25%

0.20

500

MMZ2012Y601BTD25

1000

±25%

0.30

500

MMZ2012Y102BTD25

1500

±25%

0.40

500

MMZ2012Y152BTD25

2000

±25%

0.50

400

MMZ2012Y202BTD25

80

±25%

0.30

500

MMZ2012D800BTD25

120

±25%

0.30

500

MMZ2012D121BTD25

300

±25%

0.50

400

MMZ2012D301BTD25

Measurement item

Product No.

Manufacturer

Impedance

E4991A+16192A

Keysight Technologies

DC resistance

Type-7556

Yokogawa
