2.5x2.0mm 32.768kHz SMD Oscillator

O2HK

(former FK21x, FK23x, FK24x Series)

DATASHEET

© Copyright 2020 Fox Electronics. All rights reserved

Title / Description: O2HK SERIES STANDARD SPECIFICATIONS

Drawing Number: O2HK-DOC-1

Size: A

Part Number:

Cage: 61429

Draftsperson:

MAJ

Approved: BEC

Revision Date: 02/25/2020

Page 6 of 6

Tape Specifications (millimeters)

Reel Specifications (millimeters)

A

B

C

D

E

F

Reel Qty

G

H

I

J

K

L

M

Ø1.5

4.0

4.0

3.5

8.0

1.4

-T3 = 3,000

-T2 = 2,000

-T1 = 1,000

2.5

Ø13

Ø22

Ø60

Ø178

8.0

1.6

Available Options & Part Identification

Example: F O2HK L B M 0.032768

F

O2HK

L

B

M

0.032768

Fox

Model Number

Voltage

L = 1.8V±10%

J = 2.5V±10%

C = 3.3V±10%

V = 1.7V ~ 3.63V

Stability

B = ±50 PPM

D = ±25 PPM

E = ±20 PPM

Operating

Temperature

D = -10 ~ +60ºC

F = -20 ~ +70ºC

M = -40 ~ +85ºC

Frequency
