Features

•

Input bus voltage from 6 V to 75 V with dedicated monitoring

•

MOSFETs

•

STDRIVE101 embedded features:

–

Two input strategies (enable / input with adjustable deadtime generation or

direct driving with interlocking)

–

–

Overcurrent protection with internal comparator

•

Three-shunt or single-shunt configurable current sensing

•

BEMF or Digital Hall sensor circuitries

•

NTC sensor for PCB temperature monitoring

•

Motor control connector compatible with a wide range of STM32 boards and

systems

Application

•

Power tools

•

e-Bikes

•

Fans and home appliances

Description

The EVALSTDRIVE101 is a demonstration board based on the STDRIVE101, a

three-phase gate driver, and the STL110N10F7 power MOSFETs.

The EVALSTDRIVE101 is designed to drive three-phase brushless DC motors and it

can be interfaced with different STM32 microcontrollers through the motor control

connector.

The board can be configured in single shunt and three-shunt and can support FOC

and six-step algorithms in both configurations.

The Hall sensors connector and the phase sensing network present on-board allow

to implement both sensor and sensorless algorithms for motion control.

The EVALSTDRIVE101 allows a full evaluation of the STDRIVE101 and its features,

including the embedded comparator for overcurrent protection and the drain-source

voltage sensing of each power MOSFET.

Product status link

EVALSTDRIVE101

STDRIVE101

STDRIVE101 demonstration board for three-phase brushless motors

EVALSTDRIVE101

Data brief

DB4298 - Rev 1 - October 2020
