MODEL: 10TS

http://www.m-system.co.jp/

10TS SPECIFICATIONS

ES-0812 Rev.9 Page 3/4

DIMENSIONS unit: mm (inch)

Terminal 3 is deleted with CJC sensor attached models.

130 (5.12)

3 (.12)

51 (2.01)

2–4.3 (.17) dia.

MTG HOLE

TERMINAL COVER

7–M3.5 SCREW

8 (.31)

25 (.98)

1

2

3

5

6

7

8

TERMINAL ASSIGNMENTS

1

2

5

6

7

8

CJC SENSOR

(model: CJM)

*Deleted with Option /N

*

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

Output

Driver

OUTPUT 1

7

8

+

–

S

Z

Output

Driver

OUTPUT 2

5

6

*

Deleted with Option /N.

** Deleted with Option /N or B thermocouple.

***1 output type has the output 1 connected to the card-edge connector in parallel.

Remark 1) The section enclosed by broken line is only for 2nd output channel.

OUTPUT 2***

**

POWER

S

Z

Voltage/

Duty Cycle

Low Drift

Amplifier

Burnout

Protection

+

–

T / C

CJC

SENSOR

metal leg

comp. leadwire

1

2

+

–

Linearizer

CJC Sensing

Volt. Generator

red

black

model: CJM

*
