Pin dimensions

0,8 x 0,8 mm

Hole diameter

1.45 mm

Technical data

Range of articles

EMCV 1,5/..-GF

Insulating material group

IIIa

Rated surge voltage (III/3)

2.5 kV

Rated surge voltage (III/2)

2.5 kV

Rated surge voltage (II/2)

2.5 kV

Rated voltage (III/2)

160 V

Rated voltage (II/2)

250 V

Connection in acc. with standard

EN-VDE

8 A

160 V

Maximum load current

8 A

Insulating material

PBT

Inflammability class acc. to UL 94

V0

Nominal voltage, UL/CUL Use Group B

300 V

Nominal current, UL/CUL Use Group B

8 A

Nominal voltage, UL/CUL Use Group D

300 V

Nominal current, UL/CUL Use Group D

8 A

Certificates / Approvals

Certification

CUL, GOST, UL

Accessories

Item

Designation

Description

Assembly

1877258

EMC 1,5-SH

Stamp holder, for upper and lower stamp

1877274

EMCV 1,5-SS 1

Stamp set, consisting of upper and lower stamp for 3.81 mm pitch,

2 to 16-pos.
