MODEL: M2EXT

M2EXT SPECIFICATIONS

ES-5145 Rev.3 Page 6/7

http://www.m-system.co.jp/

MODE

ITEM

SETTING PARAMETER

RANGE

UNIT

INITIAL VALUE

Option

51

Burnout

None / Down / Up

—

Up

61

Unit (OUT Scaling)

Choose from 68 types*

—

%

64

Temperature unit

°C / °F / K

—

°C

65

Cold junction compensation

CJM / FXD TEMP

—

CJM

66

Preset xed terminal temperature

-50.00 – 100.00

°C

0.00

67

Filter time constant

0 – 30

sec.

0

69

Input Zero ne adjust

-10.00 – 10.00

°C

0.00

70

Input Span ne adjust

-10.00 – 10.00

°C

0.00

71

Output Zero ne adjust

-5.000 – 5.000

%

0.000

72

Output Span ne adjust

95.000 – 105.000

%

100.000

01

Lockout setting

Lock / Unlock

—

Lock

Advanced

90

Display setting

Upper: choose from 5 types*

Lower: choose from 6 types*

—

Upper: INPUT

Lower: PERCENT

91

Brightness

1 (darkest) – 4 (brightest)

—

4

92

Display timeout

0 (always on), 1 – 60

min.

10

93

Reset all settings

OFF / RESET

—

OFF

94

Version indication

—

—

—

01

Lockout setting

Lock / Unlock

—

Lock

* For detailed types, refer to the operating manual (EM-5145-B).

EXTERNAL DIMENSIONS unit: mm (inch)

29 (1.14)

94 (3.70)

8

(.31)

124 (4.88)

22 (.87)

6 (.23)

11–M3

SCREW

29.5 (1.16)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

DIN RAIL

35mm wide

[4 (.16)]

• When mounting, no extra space is needed between units.

4

8 7

10

11

5

6

1

2

3

9

TERMINAL ASSIGNMENTS

1

6

8 7

10

11

3

9

4

2

1

5

CJC SENSOR

(model: CJM)
