MODEL: M2D2

M2D2 SPECIFICATIONS

ES-5065 Rev.10 Page 3/4

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

5

9

21.5 (.85)

84 (3.31)

10 (.39)

15 (.59)

6 (.23)

DIN RAIL

35mm wide

[4 (.16)]

8–M3

SCREW

23 (.91)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

• When mounting, no extra space is needed between units.

4

8

12

14 13

1

TERMINAL ASSIGNMENTS

9

12

14

13

SHORTCIRCUIT

WIRE

1

4

5

8

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Base Socket

Current

Limiter

9

12

+

–

*

OUTPUT 1

5

8

+

–

**

OUTPUT 2

+

– 4

1

+

–

* Short across these terminals for large voltage allowance at Output 2.

Be sure to match specifications of smart transmitter.

Do not connect a capacitive load to Output 1.

**Short across these terminals when not using output 2.

U(+)

V(–)

13

14

POWER

250Ω

LED

2-WIRE

TRANSMITTER
