MODEL: M2FV

M2FV SPECIFICATIONS

ES-5106 Rev.7 Page 3/4

http://www.m-system.co.jp/

EXTERNAL VIEW

OFF

ON

1 2 3 4 5 6

SW2

■ FRONT VIEW

■ SIDE VIEW

OFF

ON

1 2 3 4

SW1

Input Range

and Response Time

Setting

Zero Adj.

Span Adj.

Power LED

Output Range

Setting

Refer to the instruction manual for detailed procedures.

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5

9

21.5 (.85)

84 (3.31)

10 (.39)

15 (.59)

6 (.23)

DIN RAIL

35mm wide

[4 (.16)]

8–M3

SCREW

23 (.91)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

• When mounting, no extra space is needed between units.

4

8

12

14 13

1

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

9

12

1

5

8

4

13

14

Output

Driver

+

–

*

U(

+)

V(

–)

S

Z

+

–

OUTPUT

POWER

Base Socket

Isolation

Low Drift

Amplifier

INPUT

POWER LED

INPUT RANGE

& RESPONSE TIME

SELECTOR DIP SW

OUTPUT RANGE

SELECTOR DIP SW

* Input shunt resistor incorporated for current input.
