MODEL: FASD

FASD SPECIFICATIONS

ES-1416 Rev.7 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

1

2

3

4

7

6

8

5

11 12

9 10

26 (1.02)

107 (4.21)

DIN RAIL

35mm wide

[3.3 (.13)]

26 (1.02)

15

(.59)

7.8 (.31)

2–4.5 (.18)

HOLE

15 (.59) deep

12–M3.5

SCREW

CLAMP

(top & bottom)

148 (5.83)

•When mounting, no extra space is needed between units.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Base Socket

U(+)

V(–)

POWER

7

8

4

12

Comparator

+

–

INPUT

5

Low Drift

Amplifier

6

D / A

Converter

Comparator

D / A

Converter

Ry

2

3

1

Ry

10

11

9

LO OUTPUT

HI OUTPUT

* Input shunt resistor incorporated for current input.

*

9 9

THUMBWHEEL

SWITCHES

THUMBWHEEL

SWITCHES

9 9

Inductive

Load (Coil)

Varistor or Spark

Quenching Circuit

•DC Powered

Inductive

Load (Coil)

Diode, Varistor or

CR Circuit

■ Relay Protection

•AC Powered

U

LOAD

LOAD

Specifications are subject to change without notice.
