MODEL: CVRTD

CVRTD SPECIFICATIONS

ES-1320 Rev.7 Page 3/3

https://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm [inch]

3

4

5

6

2

1

8

7

50 [1.97]

107 [4.21]

127 [5]

(3.3 [.13])

40 [1.57]

50 [1.97]

7.8 [.31]

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 [.18] dia.

MTG HOLE

15 [.59] deep

8–M3.5

SCREW

• When mounting, no extra space is needed between units.

TERMINAL ASSIGNMENTS unit: mm [inch]

5

6

8

7

3

4

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.

2

1

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

–

–

+

–

Isolation

*

Base Socket

S

Z

*Input shunt resistor attached for current input.

INPUT

1

Low Drift

Amplifier

Digital

Controller

OUTPUT

R

2

5

6

+

+

3

4

U(+)

V(–)

POWER

7

8

A/D Conversion

Digital Computation

Ry

Specifications are subject to change without notice.
