MODEL: HPP

HPP SPECIFICATIONS

ES-3461 Rev.9 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

1

2

3

4

7

6

8

5

26 (1.02)

107 (4.21)

26 (1.02)

15

(.59)

2–4.5 (.18)

HOLE

15 (.59) deep

DIN RAIL

35mm wide

[3.3 (.13)]

8–M3.5

SCREW

CLAMP

(top & bottom)

137 (5.39)

•When mounting, no extra space is needed between units.

7.8 (.31)

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

LOAD

Relay or

Counter Coil

Spark Quenching

Diode

LOAD

Relay or

Counter Coil

Varistor or Spark

Quenching Circuit

U

Isolation

Base Socket

Waveform

Shaper

Output

Driver

4

12V Supply

+

–

INPUT

1

3

2

+

SENSOR EXCITATION

Timer

*

* Timer is provided for low frequency open collector or photo MOSFET relay pulse output.

4kΩ

■ Mechanical Contact or Open Collector

Input Connection Examples

+12V

■ Voltage Pulse

+12V

■ Open Collector

Output Connection Examples

+

–

5

6

+

–

■ Voltage Pulse

+

–

5

6

+

–

+

+

–

–

PWR

+

+

–

–

PWR

+

–

1

2

+ 3

+

–

1

2

+ 3

■ Photo MOSFET Relay Pulse

• AC Powered

• DC Powered

5

6

5

6

+

–

+

–

OUTPUT

5

6

POWER

7

8

Specifications are subject to change without notice.
