MODEL: JTY2

JTY2 SPECIFICATIONS

ES-1573 Rev.8 Page 4/5

http://www.m-system.co.jp/

EXTERNAL VIEW

3

2

1

2

3

4

5

6

ON

Span Adj.

Detecting Level Adj.

Detecting Level Adj. Pin

Pulse Amplitude Selector

Input Type Selector

Zero Adj.

Sensor Excitation Adj.

Modular Jack

Input Monitor LED PL1

Refer to the instruction manual for detailed procedures.

INPUT PULSE LOGIC

H

L

H

L

OFF

ON

OFF

ON

INPUT TYPE

Voltage pulse

Two-wire current pulse

ON current (H)

OFF current (L)

Open collector

The pulse logic is applied to the bold lined section of the waveform.

PULSE LOGIC

Non-inverted

Inverted

Non-inverted

Inverted

WAVEFORM

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5

6

7

8

2

1

11

10

50 (1.97)

107 (4.21)

136 (5.35)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

MTG HOLE

25 (.98) deep

SCREW

• When mounting, no extra space is needed between units.

3

9

4
