SOC50S Series

Metal DIP CMOS OCXO

50.0mm x 50.0mm

Call: +1-949-783-7300 | Fax: +1-949-783-7301

Specifications are subject

to change without notice.

www.suntsu.com

Suntsu Electronics, Inc.

142 TECHNOLOGY DR., SUITE 150

IRVINE, CA 92618

Features

Applications

Frequency Range

Freq. Stability vs. Supply Voltage

Freq. Stability vs. Aging/Year

Freq. Stability vs. Op Temp.

Operating Temperature

Storage Temperature

AT-Cut : ±300/Year, SC-Cut : ±50/Year

See part numbering guide for options.

See part numbering guide for options.

MHz

ppb

ppb

ppb

°C

°C

100

+5

±300

+70

+85

5

-5

±50

-10

-40

-45

See part numbering guide for options.

V

+10

Freq. Stability vs. Load

±10% Change

ppb

+5

-5

Frequency Tolerance at +25ºC

ppb

-100

+100

Power Consumption At Turn On

Pullability (AT-Cut)

Deviation Slope

Output Logic (Sinewave) Load

Output Logic Waveform

AT-Cut

Positive

W

ppm

%

V

KΩ

Ω

6.0

10

50

±2.0

0.0

50

Output Logic Spurious (Harmonic)

dBm

dBc

dBc

-30

-70

7

5.0

Linearity

SC-Cut

ppm

±0.5

Power Consumption At 25°C

W

2.0

V

5

Symmetry (Duty Cycle)

50

%

55

45

Pullability (SC-Cut)

Control Middle Voltage

2.5

V

Start-UP Time

ms

3

Warm-Up Time

At 25°C After 5Mins.

ppb

50

-50

Typical

Units

Electrical Parameters

Maximum

Remarks

Minimum

Cage Code: 4GUT4

To customize your parameters contact a Suntsu representative.

SUNTSU OCXO

50.0mm x 50.0mm

SINEWAVE

Part Numbering Guide

COMPLIANT

FREQUENCY STABILITY

FREQUENCY

F : ±500ppb

I : ±200ppb

J : ±100ppb

K : ±50ppb

L : ±20ppb

M : ±10ppb

N : ±7.5ppb

O : ±5.0ppb

05 : 0°C - +50°C

15 : -10°C - +55°C

2 : -20°C - +60°C

37 : -30°C - +70°C

47 : -40°C - +70°C

MHz

SUPPLY VOLTAGE

05 : 5.0V±5%

09 : 9.0V±5%

12 : 12.0V±5%

OPERATING

TEMPERATURE RANGE

SOC 50 S 12 K 47 A - 10.000M

Type Of

Crystal

A : AT-Cut

B : SC-Cut
