MODEL: M2AS1

M2AS1 SPECIFICATIONS

ES-5064 Rev.12 Page 3/5

http://www.m-system.co.jp/

EXTERNAL VIEW

Output Setpoint Adj.

Deadband Adj.

Output Monitor LED

Reset Control

9

9

9

9

EXTERNAL DIMENSIONS unit: mm (inch)

5

9

21.5 (.85)

86.7 (3.41)

7.3 (.29)

15 (.59)

6 (.23)

DIN RAIL

35mm wide

[4 (.16)]

8–M3

SCREW

23 (.91)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

116.7 (4.59)

• When mounting, no extra space is needed between units.

1

4

8

12

14 13

TERMINAL ASSIGNMENTS unit: mm (inch)

5

8

9

12

14 13

INPUT RESISTOR

(model: REM2)

Input shunt resistor attached

for current input.

1

4
