MODEL: M2TT

M2TT SPECIFICATIONS

ES-5131 Rev.4 Page 3/4

http://www.m-system.co.jp/

Pollution Degree 2

(Operational Temprature must be with -5 to +55°C (23 to

131°F))

Input or output to power: Reinforced insulation (300 V)

Input to output: Basic insulation (300 V)

RoHS Directive

EN 50581

EXTERNAL DIMENSIONS unit: mm (inch)

5

9

21.5 (.85)

84 (3.31)

10 (.39)

15 (.59)

6 (.23)

DIN RAIL

35mm wide

[4 (.16)]

8–M3

SCREW

23 (.91)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

• When mounting, no extra space is needed between units.

4

8

12

14 13

1

TERMINAL ASSIGNMENTS unit: mm (inch)

8

9

12

14 13

CJC SENSOR

(model: CJM)

1

1

4

5

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

Base Socket

S

Z

Low Drift

Amplifier

Output

Driver

OUTPUT

9

12

+

–

T / C

CJC

SENSOR

metal leg

model: CJM

comp. leadwire

1

5

4

+

–

8

Linearizer

CJC Sensing

Volt. Generator

*Deleted with B thermocouple.

*

U(+)

V(–)

POWER

13

14
