MODEL: M60SWVS

M60SWVS SPECIFICATIONS

ES-8023 Rev.1 Page 3/4

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

DIN rail

(35mm wide)

102 (4.02)

0.5 (.02)

(Test lead pin 1 dia.)

•

With the end cover attached

•

Capable of High-density mounting

1

2

3

4

5

6

7

8

6 (.24)

2 (.08)

6 (.24)

3.7 (.15)

2.1 (.08)

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

S

Z

+

−

INPUT

Low Drift

Amplifier

3

4

5

6

1

2

+

−

Output 1

Driver

Output 2

Driver

OUTPUT 1

OUTPUT 2

POWER

DIP SW for setting

various functions

DIP SW for setting

output range

S

Z

DIP SW for setting

output range

* Input shunt resistor incorporated for current input.

*

Power LED

7

8

+

−

+

−

POWER
