MODEL: WRPP

WRPP SPECIFICATIONS

ES-2222 Rev.3 Page 3/4

http://www.m-system.co.jp/

EXTERNAL VIEW

Input Monitor LED Phase B (Red)

Input Monitor LED Phase A (Green)

OUTPUT LOGIC

Applicable for both Output 1 and 2.

H

L

Voltage pulse

or

RS-422 line

driver pulse

Output

Non-inverted

Non-inverted

Dry contact

Input

H

L

H

L

OFF

ON

H

L

Inverted

Inverted

H

L

OFF

ON

OFF

ON

OFF

ON

OFF

ON

Open collector

Voltage pulse

RS-422 line driver pulse

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

50 (1.97)

72 (2.83)

107 (4.21)

136 (5.35)

[3.3 (.13)]

60 (2.36)

72 (2.83)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

14–M3.5

SCREW

• When mounting, no extra space is needed between units.

12

5

6

14

11

1

10

15

4

3

2

7

9

8
