MODEL: M2AC

M2AC SPECIFICATIONS

ES-5036 Rev.16 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5

9

21.5 (.85)

84 (3.31)

10 (.39)

15 (.59)

6 (.23)

DIN RAIL

35mm wide

[4 (.16)]

8–M3

SCREW

23 (.91)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

• When mounting, no extra space is needed between units.

4

8

12

14 13

1

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

Base Socket

INPUT

1

R.M.S.

Operation

Output

Driver

OUTPUT

4

5

8

9

12

S

Z

AC

Amplifier

*Input shunt resistor incorporated for current input.

U(+)

V(–)

POWER

13

14

*

Specifications are subject to change without notice.
