MODEL: 22LS1

22LS1 SPECIFICATIONS

ES-6557 Rev.6 Page 6/7

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

50 (1.97)

80 (3.15) min.

12 (.47)

103 (4.06)

132 (5.20)

•When mounting, no extra space is needed between units.

5

6

7

8

2

1

11

10

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

11–M3.5

SCREW

3

9

4

SYSTEM CONFIGURATION EXAMPLES

SIN-NET

Slave 1 Outputs

Slave 2 Outputs

Slave "n" Outputs

Local (Slave) Station

■ 1 to N TRANSMISSION

■ 1 to 1 TRANSMISSION

Modem

Interface

Model: 22LS1

Model: 22LS1

Model: 22LS1

Model: 22LA1

Modem

Interface

Model: 22LS1

300 bps

Modem

Model: MOD2

2

D

O

M

:

l

e

d

o

M

2

D

O

M

:

l

e

d

o

M

300 bps

Modem

Model: MOD2

SIN-NET

SIN-NET

Multi-Transmission

Module

Model: 22LA1

Model: 22LA1

Multi-Transmission

Module

Model: 22LA1

Master Station Control Room

Leased Circuit

Slave Sta. 1

SIN-NET

Leased Circuit

Master Station Control Room

Slave Sta. 2

Slave Sta. n
