Product data sheet

09 11 001 2751

Han 1HC-bu-AX (350A,35-70mm2)

Han 1HC-bu-AX (350A,35-70mm2)

Image is for illustration purposes only. Please refer to product description.

Part number

09 11 001 2751

Specification

Han 1HC-bu-AX (350A,35-70mm2)

HARTING eCatalogue

https://b2b.harting.com/09110012751

Identification

Category

Inserts

Series

Identification

350

Version

Termination method

Axial screw termination

Gender

Female

With wire protection

0

Technical characteristics

Conductor cross-section

[35] ... [70 mm²]

Wire outer diameter

[≤19,5 mm]

Rated current

350 A

Rated voltage

2000 V

Rated impulse voltage

12 kV

Pollution degree

3

Insulation resistance

Contact resistance

≤0.2 mΩ

Stripping length

[19] ... [20 mm]

Tightening torque

[8 Nm] @ 35 mm²

[10 Nm] @ 50 mm²

[12 Nm] @ 70 mm²

Limiting temperature

[-40] ... [+125 °C]
