Product data sheet

09 11 001 2652

Han 1HC-sti-AX (350A,95-120mm2)

Han 1HC-sti-AX (350A,95-120mm2)

Image is for illustration purposes only. Please refer to product description.

Part number

09 11 001 2652

Specification

Han 1HC-sti-AX (350A,95-120mm2)

HARTING eCatalogue

https://b2b.harting.com/09110012652

Identification

Category

Inserts

Series

Identification

350

Version

Termination method

Axial screw termination

Gender

Male

With wire protection

0

Technical characteristics

Conductor cross-section

[95] ... [120 mm²]

Wire outer diameter

[≤19,5 mm]

Rated current

350 A

Rated voltage

2000 V

Rated impulse voltage

12 kV

Pollution degree

3

Insulation resistance

Contact resistance

≤0.2 mΩ

Stripping length

[19] ... [20 mm]

Tightening torque

[14 Nm] @ 95 mm²

[16 Nm] @ 120 mm²

Limiting temperature

[-40] ... [+125 °C]
