MODEL: CVR1

CVR1 SPECIFICATIONS

ES-1554 Rev.9 Page 3/4

https://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm [inch]

5

6

7

8

2

1

11

10

50 (1.97)

107 (4.21)

136 (5.35)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

MTG HOLE

25 (.98) deep

SCREW

• When mounting, no extra space is needed between units.

3

9

4

TERMINAL ASSIGNMENTS unit: mm [inch]

7

8

2

1

11

10

3

9

4

INPUT RESISTOR

(model: REM)

5

6

Input shunt resistor attached

for current input.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

*

Base Socket

S

Z

*1. Input shunt resistor attached for current input.

*2. Only for power Input code M2.

INPUT

5

Input

Circuit

Servo

Amplifier

OUTPUT

R

6

9

10

U(+)

V(–)

POWER

7

8

11

M

MOTOR

1

2

3

Reference

Volt. Generetor

3

2

1

max.

min.

POTENTIOMETER

4

M

1

*

2

FE

In order to improve EMC performance, bond the FE terminal to ground.

Caution: This terminal is NOT a protective conductor terminal.
