MODEL: LPF

http://www.m-system.co.jp/

LPF SPECIFICATIONS

ES-1979 Rev.13 Page 3/3

CONNECTION DIAGRAM

■ 3-PHASE/4-WIRE

LOAD

1

N

2

3

SOURCE

P0

V

P2

U

v

u

FUSE

VT

V

v

P3

U

u

15

16

13

1

2

9

10

U(+)

V(–)

+

–

11

12

OUTPUT

■ 3-PHASE/3-WIRE

LOAD

1

2

3

SOURCE

P3

U

P2

V

u

v

FUSE

VT

k

l

CT

L

K

1L

1S

15

16

1

2

9

10

U(+)

V(–)

+

–

11

12

OUTPUT

k

l

CT

L

K

1L

1S

*The transducer can be powered from the input voltage when the voltage is sufficiently stable and meets other supply voltage requirements.

AUXILIARY POWER

*

AUXILIARY POWER

*

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

112 (4.41)

[3.3 (.13)]

DIN RAIL

35mm wide

8 (.31)

M3.5 SCREW

(Only on the used terminals)

75 (2.95)

TERMINAL

COVER

2–5.8 (.23) dia. or

2–4.8 (.18) dia.

MTG HOLE

8 (.31) deep

•When mounting, no extra space is needed between units.

9 10 11 12 13 14 15 16

1 2

3

4

5

6

7 8

MOUNTING REQUIREMENTS unit: mm (inch)

2–M5

60 (2.36)

■ M5 SCREWS

2–M4

60 (2.36)

■ M4 SCREWS

Specifications are subject to change without notice.
