LSMT2

ES-1954 Rev.6

Specifications subject to change without notice.

P. 4 / 10

CONNECTION DIAGRAM, OUTPUT & AUXILIARY SUPPLY

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENT mm (inch)

MOUNTING REQUIREMENTS mm (inch)

OUTPUT

–

AUX SUPPLY

V(–)

U(+)

–

Shielded

Twisted-pair

Cable

To Other

RS-485 Devices

■Pulse Output

■Network Output

Output 1 through 10: Analog output

Output 11: Pulse or network output

DIN RAIL

35 mm wide

4–5 (.2) dia. HOLE

[3.3 (.13)]

128 (5.04)

7 (.28)

64 (2.52)

120 (4.72)

9.2 (.36)

13–M4 SCREW

8.2 (.32)

23–M3.5 SCREW

125 (4.92) min.

64 (2.52)

4–M4
