PLL601-01

Low Phase Noise PLL Clock Multiplier

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 3

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other con-

ditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. AC Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Input Frequency

Fundamental parallel resonance

10

27

MHz

Output Frequency

At 3.3V

160

MHz

Output Rise Time

0.8V to 2.0V with no load

1.5

ns

Output Fall Time

2.0V to 0.8V with no load

1.5

ns

Duty Cycle

45

50

55

%

3. DC Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Operating Voltage

2.97

3.63

V

Input High Voltage

2

V

Input Low Voltage

0.8

V

Input High Voltage

For XIN pin

+ 1

V

Input Low Voltage

For XIN pin

− 1

V

Output High Voltage

2.4

V

Output Low Voltage

0.4

V

Output High Voltage At

CMOS Level

V

Operating Supply Current

No Load

35

mA

Short-circuit Current

±50

mA

Input Capacitance

OE, Select Pins

5

pF
