ELECTRICAL SPECIFICATIONS

ABSOLUTE MAXIMUM RATINGS

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage Range

4.6

V

Input Voltage Range

V

Output Voltage Range

V

Data Retention @ 85

º C

10

Years

Soldering Temperature

240

°C

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

+85

°C

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the device

and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other conditions above

the operational limits noted in this specification is not implied.

AC SPECIFICATIONS

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Fundamental Crystal

10

30

MHz

Crystal Input Frequency

75

MHz

Settling Time

At power-up (after VDD increases over

1.62V)

10

ms

VDD Sensitivity

Frequency vs. VDD+/-10%

-2

2

ppm

15pF Load, 10/90%VDD, Standard drive

2.5

3.5

ns

Output Rise Time

15pF Load, 10/90%VDD, High drive

1.0

1.5

ns

15pF Load, 90/10%VDD, Standard drive

2.5

3.5

ns

Output Fall Time

15pF Load, 90/10%VDD, High drive

1.0

1.5

ns

Duty Cycle

At VDD/2

45

50

55

%

Max. output skew between

same frequency clocks

Equal loading (15 pF). Equal frequency

& drive strength

500

ps

Period Jitter, peak-to-peak*

(measured from 10,000

samples)

With capacitive decoupling between VDD

and GND. Operating only one output.

40

ps

* Note: Jitter performance depends on the programming parameters.
