PLL602-14

192MHz – 400MHz Low Phase Noise LVDS XO (12 – 25MHz Crystal)

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 3

3. General Electrical Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Current, Dynamic

(with Loaded Outputs)

LVDS

60

mA

Operating Voltage

2.97

3.63

V

Output Clock Duty Cycle

@ 1.25V (LVDS)

45

50

55

%

Short Circuit Current

±50

mA

4. Jitter and Phase Noise Specification

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Period jitter RMS

With capacitive decoupling

between VDD and GND.

5

ps

Accumulated jitter RMS

With capacitive decoupling

between VDD and GND. Over

10,000 cycles.

11

ps

Phase Noise relative to carrier

311MHz @100Hz offset

-90

dBc/Hz

Phase Noise relative to carrier

311MHz @1kHz offset

-114

dBc/Hz

Phase Noise relative to carrier

311MHz @10kHz offset

-134

dBc/Hz

Phase Noise relative to carrier

311MHz @100kHz offset

-134

dBc/Hz
