PLL602-89C

12-27 MHz XO IC with 1 Pair of LVDS and 2 CMOS Outputs

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 2

PIN DESCRIPTION

Name

Pin

Number

Type

Description

VDD

1

P

Power Supply.

XIN

2

I

Crystal input. This is the input of the crystal oscillator circuitry. The crystal

should be mounted as close to the IC as possible, with minimum parasitic

capacitance.

XOUT

3

I

Crystal output. This is the output of the crystal oscillator circuitry. The crystal

should be mounted as close to the IC as possible, with minimum parasitic

capacitance.

GND

4

P

Ground.

CMOS2_ CLK

5

O

CMOS output.

LVDS_CLK

6

O

LVDS output.

LVDSBAR_CLK

7

O

LVDS complementary output.

CMOS1_CLK

8

O

CMOS output.

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other con-

ditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. Crystal Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Resonator Frequency

Parallel Fundamental Mode

12

27

MHz

Crystal Loading Rating

21.5

pF

Recommended ESR

30

Ω
