IO-Link master (EIP/MOD)

ICE2-8IOL-K45P-RJ45

EtherNet/IP IO-Link master with 8 inputs/outputs, DIN rail, push-in connectors

Function

The module is an EtherNet/IP fieldbus module with 8 type A IO-Link master ports according to the IO-Link standard V1.1.

The module serves as an interface between the controller of an EtherNet/IP fieldbus system and IO-Link devices at the field level. The integrated

web server and IODD interpreter enables complete configuration of the module and attached IO-Link devices without the need for special

software tools. Information regarding the status of the module is also displayed and network parameters such as the IP address and subnet mask

can be configured. The module is capable of storing all configuration enabling stand-alone usage without a higher-level PLC. MutliLink

simultaneously provides data access via different communication protocols like EtherNet/IP, Modbus/TCP and OPC UA to multiple controllers.

A pluggable push-in connector supplies power enabling a current rating of up to 3.7 A.

The inputs and outputs are equipped with pluggable, push-in connectors. Connection to the fieldbus is achieved using a standard RJ45 Ethernet

connector.

Status information for each channel is displayed via LEDs as a diagnostic function.

Dimensions

45.2

113.6

1
