PLL520-88/-89

Low Phase Noise VCXO (9.5-65MHz)

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/20/04 Page 2

PIN AND PAD ASSIGNMENT

Name

Pin#

Description

VDD

1

Power Supply.

XIN

2

Crystal input. See Crystal Specification on page 3.

XOUT

3

Crystal output. See Crystal Specification on page 3.

DNC

4

Do Not Connect.

S2

5

Output Divide by Two selector pin. See the OUTPUT DIVIDE BY TWO SELECTOR Table on

page 1.

OE_CTRL

6

Output Enable input. See OUTPUT SELECTION AND ENABLE TABLE on page 1.

VCON

8

Voltage control input.

GND

9

Ground.

GNDBUF

10

Ground for output buffer circuitry.

Q

11

PECL or LVDS output.

VDDBUF

12

Power supply for output buffer circuitry.

QBAR

13

Complementary PECL or LVDS output.

GNDBUF

14

Ground for output buffer circuitry.

DNC

15

Do Not Connect.

DNC

16

Do Not Connect.

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.
