PLL601-22

27MHz Multiple output XO with Audio Clock

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 11/19/04 Page 4

PACKAGE INFORMATION

C

L

A

EH

D

A1

e

B

16 PIN SSOP ( inch )

Sym bol

M in.

Nom .

A

.053

.064

A1

.004

.006

B

.008

C

.007

D

.189

.193

E

.150

.154

H

.228

.236

L

.016

.025

e

.025 BASIC

Max.

.069

.010

.012

.010

.197

.157

.244

.050

-

-

ORDERING INFORMATION

PhaseLink Corporation, reserves the right to make changes in its products or specifications, or both at any time without notice. The information

furnished by Phaselink is believed to be accurate and reliable. However, PhaseLink makes no guarantee or warranty concerning the accuracy of said

information and shall not be responsible for any loss or damage of whatever nature resulting from the use of, or reliance upon this product.

LIFE SUPPORT POLICY: PhaseLink’s products are not authorized for use as critical components in life support devices or systems without the

express written approval of the President of PhaseLink Corporation.

For part ordering, please contact our Sales Department:

47745 Fremont Blvd., Fremont, CA 94538, USA

Tel: (510) 492-0990 Fax: (510) 492-0991

PART NUMBER

The order number for this device is a combination of the following:

Device number, Package type and Operating temperature range

PLL601-22 X X X X

Order Number

Marking

Package Option

PLL601-22XC

P601-22XC

16-pin SSOP - Tube

PLL601-22XC-R

P601-22XC

16-pin SSOP - Tape and Reel

PLL601-22XCL

P601-22XCL

16-pin SSOP - Tube

PLL601-22XCL-R

P601-22XCL

16-pin SSOP - Tape and Reel

PART NUMBER

TEMPERATURE

C=COMMERCIAL, I=INDUSTRIAL

PACKAGE TYPE

X=SSOP

NONE=NORMAL PACKAGE

L=GREEN PACKAGE

NONE= TUBE

R=TAPE AND REEL
